Name of produc：DP-96X96-3 Single-phase DC Voltmeter
Category Digital Voltmeter > DP-XX-3
Model DP-96X96-3 Single-phase DC Voltmeter
Technical Data
Accuracy: Voltage accuracy class 0.5.
Parameters:
Rated voltage: DC 2V、DC 20V、DC 200V、DC 600V.
Overload Rating: 1.2X rating (continuous) 2X rating for 1 seconds.
Internal resistance: ≥1kΩ/ V(for non-mA/mV inputs only).
Auxiliary Power Supply: AC/DC 48~240V、AC/DC 80~265V、AC 380V、AC 220V、AC 110V、AC 60V.
Display Features:
High-brightness display.
Display data full range 1-9999 arbitrary variable settings.
Display “HHHH”, when data over 1.4 times the full range.
Operating Environment:
Operating temperature:-10℃~+55℃.
Storage temperature:-25℃~+70℃.
Relative humidity≤93%，Non corrosive gas.
Safety Performance:
Insulation resistance: ＞100MΩ.
AC withstand voltage: ＞AC 2000V.
EMC:
ESD: Level 4
Surge: Level 4
RF: Level 3
EFT: Level 3
Signal Wiring Diagram:
